Atlas Air Compressor Oil Pipe High-Pressure 3000 PSI

Products

Gardner Denver Air Compressor Parts

Ingersoll-Rand Air Compressor Parts

Atlas Air Compressor Oil Pipe High-Pressure 3000 PSI

MOQ:	1
Price:	USD37/pcs
Delivery Period:	15-20 work days
Payment Method:	T/T
Supply Capacity:	100-1000

Detail Information

Product Description

Detail Information

Place of Origin

China

Brand Name

Atlas

Model Number

2901019100

Highlight:

Atlas air compressor oil pipe

Atlas compressor spare parts

high quality air compressor parts

Product Description

Atlas Oil Pipe 2205267668 High Quality Spare Parts for Air Compressors

Product Introduction: Hydraulic & Industrial Oil Pipe

What is an Oil Pipe?

An oil pipe is a specialized conduit designed for the efficient and safe transportation of hydraulic fluids, lubricants, fuels, and other industrial oils within a system. Engineered to withstand high pressures, temperature fluctuations, vibration, and potential chemical aggression, these pipes serve as the essential vascular system of machinery, ensuring oil reaches critical components without leakage or failure.

Key Functions & Purposes

The primary function of an oil pipe is reliable fluid conveyance with these specific purposes:

Power Transmission: Transporting high-pressure hydraulic fluid to transfer power throughout a system.
Lubrication Delivery: Supplying lubricating oil to bearings, gears, and other moving parts to reduce friction and wear.
Fuel Transfer: Delivering fuel from tanks to engines or combustion systems.
Heat Transfer: Circulating oil as a cooling medium in heat exchangers and cooling systems.
Return Lines & Drainage: Providing a path for oil to return to the reservoir or sump.

Key Features & Benefits

Feature	Benefit
High-Pressure Resistance	Constructed from high-strength materials (e.g., carbon steel, stainless steel) to withstand system surge pressures without bursting.
Corrosion & Erosion Resistance	Internal and external coatings protect against rust from moisture and wear from fluid-borne particles.
Seamless Construction	Eliminates potential weak points for leaks or failures in high-pressure applications.
Precise Dimensions	Consistent inner and outer diameters ensure proper flow characteristics and fitting attachment.
Durability & Fatigue Resistance	Withstands constant vibration, pressure cycles, and mechanical stress for long service life.
Cleanliness	Internally clean and often pre-treated to prevent contamination of sensitive hydraulic systems.

Common Types of Oil Pipes

Type	Description	Primary Application
Seamless Steel Hydraulic Tube	Cold-drawn, precision-sized tubing with smooth interior finish.	High-pressure hydraulic lines and manifolds - the industry standard for reliability.
Hydraulic Hose Assembly	Flexible hose with reusable or crimped fittings on each end.	Connections between moving components where flexibility and vibration damping are required.
Welded & Drawn (W&D) Tube	Welded seam that is then drawn through a die to smooth the interior.	Medium-pressure hydraulic systems and lubrication lines - a cost-effective alternative.
Stainless Steel Tube	Offers superior corrosion resistance for harsh environments or specific fluids.	Marine applications, chemical processing, food & beverage machinery.
Carbon Steel Pipe (Schedule)	Thick-walled, threaded, used for larger diameter supply and return lines.	Low-pressure oil return lines, reservoir vent lines, and large-volume transfer.
Copper & Brass Tubing	Easily bent and corrosion-resistant, but not for high pressures.	Low-pressure lubrication systems and instrument lines.

Technical Specifications

Size Range: From small capillary tubes (¼" OD) to large diameter pipes (several inches).
Pressure Rating: Varies by type; seamless tubes can handle several thousand PSI.
Temper: Annealed (soft for bending) or hard-drawn (for straight runs).
Material: Carbon Steel (ST37, ST52), Stainless Steel (304, 316L), Copper, Aluminum.
Standards: Manufactured to DIN 2391, ASTM A179, SAE J525.
Surface Treatment: Phosphated, Galvanized, Pickled & Oiled.

Industries & Applications

Oil pipes are critical in virtually every sector that uses fluid power or lubrication:

Mobile Hydraulics: Excavators, bulldozers, agricultural tractors, and forklifts.
Industrial Machinery: Injection molding machines, metal presses, CNC machine tools.
Power Generation: Hydraulic control systems in turbines and lubrication systems in generators.
Transportation: Fuel lines, brake lines, and hydraulic systems in trucks, buses, and aircraft.
Marine & Offshore: Steering gear, winch systems, and engine room hydraulics.
Mining & Forestry: Heavy-duty equipment operating in extreme conditions.

Selection Guide: How to Choose the Right Oil Pipe

Selecting the correct oil pipe is critical for system safety and performance. Consider these factors:

Operating Pressure: Choose a pipe with a pressure rating exceeding the system's maximum working pressure.
Fluid Compatibility: Ensure the pipe material is chemically compatible with the oil type.
Environment: Consider temperature, exposure to chemicals, saltwater, UV radiation, and abrasion potential.
Flexibility vs. Rigidity: Use rigid tubing for fixed layouts and flexible hose where vibration or movement is needed.
Size (ID & OD): Inner diameter must maintain acceptable flow velocity; outer diameter must match standard port sizes.

Why Choose Our Oil Pipes?

Certified Quality: Manufactured to exacting international standards (DIN, ASTM, SAE) with full material traceability.
Superior Performance: Excellent surface finish minimizes friction and pressure loss.
Expert Technical Support: Our team helps select the right material, size, and specification for your application.
Complete Range: Comprehensive inventory of tubing, hose, and fittings for all hydraulic needs.
Customization: Cutting, bending, and threading services for ready-to-install components.

Ordering Information

To select the correct oil pipe, please provide these details:

Application: (e.g., High-Pressure Hydraulic Line, Lubrication Supply, Fuel Return)
Fluid Type: (e.g., Petroleum-based Hydraulic Oil, HFD-R Fire Resistant Fluid, Diesel Fuel)
Operating Pressure: (Maximum Working Pressure in PSI or bar)
Operating Temperature: (Range in °F or °C)
Required Dimensions: Outer Diameter (OD) and Inner Diameter (ID) or standard size designation.
Length & Configuration: (Straight length, or required bend angles and dimensions)
Material & Finish: (e.g., Carbon Steel ST52, Phosphated; Stainless Steel 304)
Required Standards/Certifications: (e.g., DIN 2391, ASTM A179)
